Customized 2D welding table

Adjustment range: 5-100mm (28 series), 5-50mm (16 series)
Small adjustment accuracy 1.0mm
Washers with standard thickness can observe the change of adjustment size
Any hole position of the same system can be applied
O-rings are evenly distributed on the shaft, which can be self-locked at any position
Standard holes can be easily connected and combined with other accessories

The flatness of the hole system table can be made according to the requirements of various levels of precision according to the needs of customers.
It is suitable for welding and assembly of products that require high flatness, and it can also be used as a testing tool with accessories.
The main material of the welding table is high-strength cast iron, which is both strong and wear-resistant. At the same time, the cast iron table does not stick to welding slag to protect the flatness of the table.
In order to meet the needs of different products, we have developed the following specifications, and several specifications can also be put together for the assembly of large equipment.
This type of tooling can be used for manual welding and robotic welding.
